Horizontal ListView

In quest'articolo troverete il codice per gestire una ListView in Android con orientamento orizzontale. La classe java da utilizzare è HorizotalListView.java, alla quale come per una ListView normale andremo a settare un Adapter a piacimento.


Nel nostro esempio la list ha un Layout custom con un immagine ed un testo. Per utilizzare la lista con orientamento orizzontale dobbiamo richiamarla nel nostro file xml del MainActivity.

...
<com.ldl.myapplication.HorizontalListView
        android:id="@+id/listview"
        android:layout_width="match_parent"
        android:layout_height="wrap_content">

    </com.ldl.myapplication.HorizontalListView>
...

Fatto ciò possiamo settare la lista con il nostro adapter che gestisce il layout custom.

package com.ldl.myapplication;

import android.content.Context;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.BaseAdapter;
import android.widget.ImageView;
import android.widget.TextView;


public class ListAdapter extends BaseAdapter {

    private Context mContext;
    private LayoutInflater mInflater;

    public ListAdapter(Context context){
        this.mContext = context;
        mInflater = (LayoutInflater) mContext.getSystemService(Context.LAYOUT_INFLATER_SERVICE);
    }
    @Override
    public int getCount() {
        return 7;
    }

    @Override
    public Object getItem(int position) {
        return null;
    }

    @Override
    public long getItemId(int position) {
        return 0;
    }

    @Override
    public View getView(int position, View convertView, ViewGroup parent) {
        ViewHolder holder = null;
        if(convertView == null){
            holder = new ViewHolder();
            convertView = mInflater.inflate(R.layout.row, null);
            holder.mImg = (ImageView) convertView.findViewById(R.id.img);
            holder.mtext = (TextView) convertView.findViewById(R.id.text);
            convertView.setTag(holder);
        }
        return convertView;
    }

    private static class ViewHolder{
        TextView mtext;
        ImageView mImg;
    }
}



E questo è il layout.

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:orientation="horizontal"
    android:layout_width="match_parent"
    android:layout_height="42dp">

    <ImageView
        android:id="@+id/img"
        android:layout_width="42dp"
        android:layout_height="42dp"
        android:src="@mipmap/ic_launcher"/>
    <TextView
        android:id="@+id/text"
        android:layout_width="wrap_content"
        android:layout_height="42dp"
        android:layout_marginLeft="10dp"
        android:gravity="center"
        android:text="ldldroid"/>
</LinearLayout>



Diseguito il codice della HorizontalListView

package com.ldl.myapplication;

import android.annotation.TargetApi;
import android.content.Context;
import android.database.DataSetObserver;
import android.graphics.Rect;
import android.os.Build;
import android.util.AttributeSet;
import android.view.GestureDetector;
import android.view.MotionEvent;
import android.view.View;
import android.widget.Adapter;
import android.widget.AdapterView;
import android.widget.ListAdapter;
import android.widget.Scroller;

import java.util.LinkedList;
import java.util.Queue;


public class HorizontalListView extends AdapterView {

    public boolean mAlwaysOverrideTouch = true;
    protected ListAdapter mAdapter;
    private int mLeftViewIndex = -1;
    private int mRightViewIndex = 0;
    protected int mCurrentX;
    protected int mNextX;
    private int mMaxX = Integer.MAX_VALUE;
    private int mDisplayOffset = 0;
    protected Scroller mScroller;
    private GestureDetector mGesture;
    private Queue<View> mRemovedViewQueue = new LinkedList();
    private OnItemSelectedListener mOnItemSelected;
    private OnItemClickListener mOnItemClicked;
    private OnItemLongClickListener mOnItemLongClicked;
    private boolean mDataChanged = false;

    public HorizontalListView(Context context) {
        super(context);
        initView();
    }

    public HorizontalListView(Context context, AttributeSet attrs) {
        super(context, attrs);
    }

    public HorizontalListView(Context context, AttributeSet attrs, int defStyleAttr) {
        super(context, attrs, defStyleAttr);
    }

    @TargetApi(Build.VERSION_CODES.LOLLIPOP)
    public HorizontalListView(Context context, AttributeSet attrs, int defStyleAttr, int defStyleRes) {
        super(context, attrs, defStyleAttr, defStyleRes);
    }

    private synchronized void initView() {
        mLeftViewIndex = -1;
        mRightViewIndex = 0;
        mDisplayOffset = 0;
        mCurrentX = 0;
        mNextX = 0;
        mMaxX = Integer.MAX_VALUE;
        mScroller = new Scroller(getContext());
        mGesture = new GestureDetector(getContext(), mOnGesture);
    }

    protected boolean onDown(MotionEvent e) {
        mScroller.forceFinished(true);
        return true;
    }

    protected boolean onFling(MotionEvent e1, MotionEvent e2, float velocityX, float velocityY) {
        synchronized (HorizontalListView.this) {
            mScroller.fling(mNextX, 0, (int) -velocityX, 0, 0, mMaxX, 0, 0);
        }
        requestLayout();
        return true;
    }

    private GestureDetector.OnGestureListener mOnGesture = new GestureDetector.SimpleOnGestureListener() {
        @Override
        public boolean onDoubleTap(MotionEvent e) {
            return super.onDoubleTap(e);
        }

        @Override
        public boolean onDoubleTapEvent(MotionEvent e) {
            return super.onDoubleTapEvent(e);
        }

        @Override
        public boolean onDown(MotionEvent e) {
            return HorizontalListView.this.onDown(e);
        }

        @Override
        public boolean onFling(MotionEvent e1, MotionEvent e2, float velocityX, float velocityY) {
            return HorizontalListView.this.onFling(e1, e2, velocityX, velocityY);
        }

        @Override
        public void onLongPress(MotionEvent e) {
            int childCount = getChildCount();
            for (int i = 0; i < childCount; i++) {
                View child = getChildAt(i);
                if (isEventWithinView(e, child)) {
                    if (mOnItemLongClicked != null) {
                        mOnItemLongClicked.onItemLongClick(HorizontalListView.this, child,
                                mLeftViewIndex + 1 + i, mAdapter.getItemId(mLeftViewIndex + 1 + i));
                    }
                    break;
                }
            }
        }

        private boolean isEventWithinView(MotionEvent e, View child) {
            Rect viewRect = new Rect();
            int[] childPosition = new int[2];
            child.getLocationOnScreen(childPosition);
            int left = childPosition[0];
            int right = left + child.getWidth();
            int top = childPosition[1];
            int bottom = top + child.getHeight();
            viewRect.set(left, top, right, bottom);
            return viewRect.contains((int) e.getRawX(), (int) e.getRawY());
        }

        @Override
        public boolean onScroll(MotionEvent e1, MotionEvent e2, float distanceX, float distanceY) {
            synchronized (HorizontalListView.this) {
                mNextX += (int) distanceX;
            }
            requestLayout();
            return true;

        }

        @Override
        public void onShowPress(MotionEvent e) {
            super.onShowPress(e);
        }

        @Override
        public boolean onSingleTapConfirmed(MotionEvent e) {
            for (int i = 0; i < getChildCount(); i++) {
                View child = getChildAt(i);
                if (isEventWithinView(e, child)) {
                    if (mOnItemClicked != null) {
                        mOnItemClicked.onItemClick(HorizontalListView.this, child,
                                mLeftViewIndex + 1 + i, mAdapter.getItemId(mLeftViewIndex + 1 + i));
                    }
                    if (mOnItemSelected != null) {
                        mOnItemSelected.onItemSelected(HorizontalListView.this, child,
                                mLeftViewIndex + 1 + i, mAdapter.getItemId(mLeftViewIndex + 1 + i));
                    }
                    break;
                }
            }
            return true;
        }

        @Override
        public boolean onSingleTapUp(MotionEvent e) {
            return super.onSingleTapUp(e);
        }
    };

    private synchronized void reset() {
        initView();
        removeAllViewsInLayout();
        requestLayout();
    }

    @Override
    public ListAdapter getAdapter() {
        return mAdapter;
    }

    @Override
    public void setAdapter(Adapter adapter) {

    }

    private DataSetObserver mDataObserver = new DataSetObserver() {
        @Override
        public void onChanged() {
            synchronized (HorizontalListView.this) {
                mDataChanged = true;
            }
            invalidate();
            requestLayout();
        }

        @Override
        public void onInvalidated() {
            reset();
            initView();
            requestLayout();
        }
    };

    //@Override
    public void setAdapter(ListAdapter adapter) {
        if (mAdapter != null) {
            mAdapter.unregisterDataSetObserver(mDataObserver);
        }
        mAdapter = adapter;
        mAdapter.registerDataSetObserver(mDataObserver);
        reset();
    }

    @Override
    public View getSelectedView() {
        return null;
    }

    @Override
    public void setSelection(int i) {

    }

    @Override
    public void setOnItemClickListener(OnItemClickListener listener) {
        mOnItemClicked = listener;
    }

    @Override
    public void setOnItemSelectedListener(OnItemSelectedListener listener) {
        mOnItemSelected = listener;
    }

    @Override
    public void setOnItemLongClickListener(OnItemLongClickListener listener) {
        mOnItemLongClicked = listener;
    }

    @Override
    protected synchronized void onLayout(boolean changed, int left, int top, int right, int bottom) {
        super.onLayout(changed, left, top, right, bottom);
        if (mAdapter == null) {
            return;
        }
        if (mDataChanged) {
            int oldCurrentX = mCurrentX;
            initView();
            removeAllViewsInLayout();
            mNextX = oldCurrentX;
            mDataChanged = false;
        }
        if (mScroller.computeScrollOffset()) {
            int scrollx = mScroller.getCurrX();
            mNextX = scrollx;
        }
        if (mNextX <= 0) {
            mNextX = 0;
            mScroller.forceFinished(true);
        }
        if (mNextX >= mMaxX) {
            mNextX = mMaxX;
            mScroller.forceFinished(true);
        }
        int dx = mCurrentX - mNextX;
        // removeNonVisibleItems(dx);
        fillList(dx);
        positionItems(dx);
        mCurrentX = mNextX;
        if (!mScroller.isFinished()) {
            post(new Runnable() {
                @Override
                public void run() {
                    requestLayout();
                }
            });
        }
    }

    private void positionItems(int dx) {
        if (getChildCount() > 0) {
            mDisplayOffset += dx;
            int left = mDisplayOffset;
            for (int i = 0; i < getChildCount(); i++) {
                View child = getChildAt(i);
                int childWidth = child.getMeasuredWidth();
                child.layout(left, 0, left + childWidth, child.getMeasuredHeight());
                left += childWidth;
            }
        }
    }

    private void fillList(int dx) {
        int edge = 0;
        View child = getChildAt(getChildCount() - 1);
        if (child != null) {
            edge = child.getRight();
        }
        fillListRight(edge, dx);
        edge = 0;
        child = getChildAt(0);
        if (child != null) {
            edge = child.getLeft();
        }
        fillListLeft(edge, dx);
    }

    private void fillListLeft(int leftEdge, int dx) {
        while (leftEdge + dx > 0 && mLeftViewIndex >= 0) {
            View child = mAdapter.getView(mLeftViewIndex, mRemovedViewQueue.poll(), this);
            addAndMeasureChild(child, 0);
            leftEdge -= child.getMeasuredWidth();
            mLeftViewIndex--;
            mDisplayOffset -= child.getMeasuredWidth();
        }
    }

    private void fillListRight(int rightEdge, int dx) {
        while (rightEdge + dx < getWidth() && mRightViewIndex < mAdapter.getCount()) {
            View child = mAdapter.getView(mRightViewIndex, mRemovedViewQueue.poll(), this);
            addAndMeasureChild(child, -1);
            rightEdge += child.getMeasuredWidth();
            if (mRightViewIndex == mAdapter.getCount() - 1) {
                mMaxX = mCurrentX + rightEdge - getWidth();
            }
            if (mMaxX < 0) {
                mMaxX = 0;
            }
            mRightViewIndex++;
        }

    }

    private void addAndMeasureChild(View child, int viewPos) {
        LayoutParams params = child.getLayoutParams();
        if (params == null) {
            params = new LayoutParams(LayoutParams.FILL_PARENT, LayoutParams.FILL_PARENT);
        }
        addViewInLayout(child, viewPos, params, true);
        child.measure(MeasureSpec.makeMeasureSpec(getWidth(), MeasureSpec.AT_MOST),
                MeasureSpec.makeMeasureSpec(getHeight(), MeasureSpec.AT_MOST));
    }

    @Override
    public boolean dispatchTouchEvent(MotionEvent ev) {
        boolean handled = super.dispatchTouchEvent(ev);
        if (mGesture != null) {
            handled |= mGesture.onTouchEvent(ev);
        }
        return handled;
    }
}
